Description

Product description:

MODEL : QLF40A

TYPE : PACKGED UNIT

COOLING CAPACITY : 4000 W/1.4T

INPUT POWER : 4153 W

OPERATING VOLTAGE : 380V/415 V or as per requirements.

PHASE : THREE PHASE

AIR VOLUME : 1000 M3/H

APPLICATION : INDUSTRIAL

ADDITIONAL INFORMATION : FOR EOT CRANE

Application:

The high-temperature special air conditioners of this series are mainly applied for lowering the indoor temperature of the operator cabs of traveling crane, operator rooms and electrical rooms ,where the ambient temperature is below 65℃, and can maintain the indoor temperature between 18℃ and 35℃. This series of conditioners are separate style.

Product features：

* The compressor adopted is the advanced flexible eddy compressor. It is featured with vibration-resistance and high energy efficiency.

* Small volume, about 35％ smaller than like products.

* Outdoor fan electromotor, F insulation, anti-high temperature about 155 ℃ ,quiet operation and vibration-resistance.

* Highly efficient internal threading heat exchanging tubes are applied to the heat exchanger, as provides high heat exchanging efficiency.

* The units adopt high and low pressure protection.

* Overload protection adopted for motors makes electrical equipments safely and reliably.

* Low noise unit (dB)
* Easy to install and operate
* R410a eco-friendly refrigerant, no damage to ozone layer
