Custom Water Spraying Nozzles

Applications:

1.Agriculture,industry humidification;

2.Cooling systems;
3.Fog systems;

Technical:

1.Thread Size: 3/16unc,10/24unc,12/24unc, 10/32unf, 6mm, 8mm.

2.SS orifice Size: 0.1mm ,0.2m,0.3mm ,0.4mm ,0.5mm and larger. Ceramic Orifice

Size:0.08mm ,0.1mm,0.2mm,0.3mm ,0.4mm ,0.5mm and larger.

3.Water Drop Size: 15 micron—70 micron.

4.With Anti-drop Device inside Nozzle.

5.High working pressure: up to 1300psi (80bar)

6.Without airs supplementary, system device is simple.

  1. 7. Energy and water saving, low cost and good effects.
  2. 8. Nozzle tip uses wear-resistant materials, and service life is 2.5 times of similar nozzle.
     Product name :      Mist/fog nozzle
     Meterial :      Brass/brass plated/SS304, custom
     Spray pattern:      Cone fog spraying
     Application :      Mist cooling/humidifying
     Thread size:      3/16unc,10/24unc,12/24unc, 10/32unf, 6mm, 8mm,custom
     Orifice size:      0.08mm, 0.1m-0.5mm, custom
     Spray angle:      65-90 degree, custom
     Installation:      Quick Release
     Working pressure:      Could be high pressure or low pressure
