Disc granulator
High Quality Disc Granulator/ Disc Balling Machine For Sinter Process Disc Pelletizer
Description
The design of disc granulator machine is convenient for intermittent continuous production, which greatly reduces the labor intensity and improves labor efficiency.The reduction gears and motor using the flexible belt driving, smooth start, slowing impact, extend equipment service life. It is the main equipment to make the powder form material into ball, mainly used in the cement industry, steel industry, etc.
Technical parameter
| Nominal diameter (mm) |
2800 | 3200 | 4200 | 4500 | 5500 | 6000 | |
| Height(mm) | 350 | 400 | 450 | 450 | 600 | ||
| Inclination | 48-54º | 45-50º | 40-50º | 40-50º | 43-53º | ||
| Rotation speed (r/min) |
11.22 | 9.09 | 7,8,9 | 8,9,10 | 6,7,8 | 6.23,6.85,7.02 | |
| Capacity (t/h) |
16 | 15-20 | 22-28 | 26-30 | 30-36 | 50-60 | |
| Main motor |
Power(KW) | 22 | 55 | 55 | 75 | 90 | |
| Voltage(V) | 380 | ||||||
| Weight(t) | 6.03 | 6.36 | 15.5 | 19.5 | 37.52 | 42.97 | |
Advantage
- The machine equipped with electric rotary bottom scrapers and edge scrapers.
- Our company can design and manufacture different specifications of disc balling machine according to customer’s demand.
- It has a very strong adaptability of raw materials.
- The production of pellets have high grade of iron and metallurgical properties, is capable for long time preservation and long-distance transport.
