PUMP

HOT WATER CIRCULATING PUMP TO BE SUPPLIED WITH COUPLING, MECHANICAL SEAL, OPTION MOTOR, AND ETC.

Description

Overview



Certificate: Inspection/Test reports, Qualified certification.

Guarantee: 18months from the date of shipment or 12 months from the date of received, which ever is early.

After-sales service provided: Online-support installation, commissioning and training.



Special Features



※ This pump has reasonable structure, seal security, excellent and reliable performance,suitable for convering no solid particles high temperature liquid.The anti-corrosion and using temperature are based on the material of main parts.

※ Inlet diameter 40-300mm, Capacity 4.5-1200m³/h, Head 26-88m, Power 1.5-250Kw

※ Used in metallurgy,electricity,rubber,textile,chemical etc to circulate hot water and to pump high temperatured high-pressured water.

※ According to the user’s actual situation to provide various type of non-standard pump design and manufacturing.







Product Characteristics
1. Standard GB/T5656-2008, GB/T3216-2005





2.TYPE:SINGLE STAGE

FLOW : 450 M3/HR

HEAD : 35 M

POWER : 75 KW

SPEED : 1480 RPM

INLET PRESSURE : 3.2 MPa

TEMPERATURE RATING : 265 DEGC

MODEL:250RII -35
